Introduction of Bottle Blow Molding Machine JND-90:
1. Application: JND-90 Bottle Blow Molding Machine is especially designed for producing 5 gallon bottles and 25L wide mouth jars;
2. Max. output: 90 BPH for 5-gallon bottles;
3. Main components
(1) main units;
(2) rotary infrared heater: the infrared heater with high penetrative force can heat the inside and outside of preform simultaneously, which help giving our bottle blow machines high shaping ability.
4. Easy operation for its high automation: only one operator is needed and the operator only need to put heated preform into the blow mold and press the switch; the following processes will be automatically completed.

Paramètres techniques:

Model	JND-90
Clamping Force	30T
Clamping Stroke	330mm
Max. Stretching Stroke	450mm
Bottom Moving Stroke	--
Number of Cavities	1 Cavity
Theoretical Output	90BPH
Max. Mould Thickness	380mm
Space Between Tie Bars	480*550mm
Electrical System
Voltage Standard	AC 380V/50HZ
Number of Heating Zone	2 Sections
Total Power(Full Loaded)	15kw
Container
Max. Container Volume	25L
Neck Diameter Range	65mm
Max. Container Diameter	330mm
Max. Container Height	550mm
Auxiliary System
Low Air compressor	8-10Bar
High Air compressor	30Bar
Air Dryer	2.0/30
Dimension & Weight (LWH)
Blow molding machine	15508202000mm
Preform Oven	25206801550mm
Net Weight	1.4Ton
