Raccords PEX laiton à insérer pour les États-Unis - HS240
Demande de devis
Raccords pour tubes PEX
Caractéristiques
- Convient aux systèmes de plomberie
- Possibilités de filetage : Filetage mâle NPT, filetage femelle NPSM
- Conforme aux normes ANSI/ASME B1.20.1 et F1807
- Options de matériaux : Laiton C46500
| TAILLE | Dimension nominale et Tolérance | ||||
| A(mm) | B(mm) | C(mm) | |||
| 3/8" | Ф8.76 | ±0.1 | 5.85 | 0.1 | MIN16.0 |
| 1/2" | Ф11.96 | ±0.1 | 8.89 | 0.1 | MIN16.0 |
| 5/8" | Ф14.48 | ±0.1 | 11.46 | 0.1 | MIN16.0 |
| 3/4" | Ф16.94 | ±0.1 | 13.47 | 0.1 | MIN16.0 |
| 1" | Ф21.74 | ±0.1 | 18.04 | 0.1 | MIN20.5 |
| 1 1/4" | Ф26.54 | ±0.1 | 22.1 | 0.1 | MIN24.0 |
| 1 1/2" | Ф31.32 | ±0.15 | 25.91 | 0.15 | MIN29.0 |
| 2" | Ф40.69 | ±0.15 | 34.68 | 0.15 | MIN38.0 |
Structure
- Accouplement droit
- Raccord coudé
- Raccord en T
Couplage droit
Coupleur égal et Coupleur réducteur, HS240-001
| TAILLE | ||
| 3/8“×3/8“ | 1/2“×3/8“ | 1 1/2“×1 1/4“ |
| 1/2“×1/2“ | 3/4“×1/2“ | 2“×1“ |
| 5/8“×5/8“ | 3/4“×5/8“ | 2“×1 1/4“ |
| 3/4“×3/4“ | 1“×3/4“ | 2“×1 1/2“ |
| 1“×1“ | 1 1/4“×3/4“ | |
| 1 1/4“×1 1/4“ | 1 1/4“×1“ | |
| 1 1/2“×1 1/2“ | 1 1/2“×3/4“ | |
| 2“×2“ | 1 1/2“×1“ | |
Adaptateur femelle fileté, HS240-002
| TAILLE | ||
| 3/8“×1/2"F | 3/4“×3/4"F | 1 1/2“×1 1/2"F |
| 1/2“×1/2"F | 3/4“×1"F | 2“×2"F |
| 1/2“×3/4"F | 1“×3/4"F | |
| 5/8“×1/2"F | 1“×1"F | |
| 5/8“×3/4"F | 1 1/4“×1"F | |
| 3/4“×1/2"F | 1 1/4“×1 1/4"F | |
Adaptateur mâle fileté, HS240-003
| TAILLE | ||
| 3/8“×1/2"M | 3/4“×3/4"M | 1 1/2“×1 1/2"M |
| 1/2“×1/2"M | 3/4“×1"M | 2“×2"M |
| 1/2“×3/4"M | 1“×3/4"M | |
| 5/8“×1/2"M | 1“×1"M | |
| 5/8“×3/4"M | 1 1/4“×1"M | |
| 3/4“×1/2"M | 1 1/4“×1 1/4"M | |
Adaptateur femelle de sueur, HS240-004
| TAILLE | ||
| 3/8“×1/2"F | 3/4“×3/4"F | 1 1/2“×1 1/2"F |
| 1/2“×1/2"F | 3/4“×1"F | 2“×2"F |
| 1/2“×3/4"F | 1“×3/4"F | |
| 5/8“×1/2"F | 1“×1"F | |
| 5/8“×3/4"F | 1 1/4“×1"F | |
| 3/4“×1/2"F | 1 1/4“×1 1/4"F | |
Adaptateur mâle de sueur, HS240-005
| TAILLE | ||
| 3/8“×1/2"M | 3/4“×3/4"M | 1 1/2“×1 1/2"M |
| 1/2“×1/2"M | 3/4“×1"M | 2“×2"M |
| 1/2“×3/4"M | 1“×3/4"M | |
| 5/8“×1/2"M | 1“×1"M | |
| 5/8“×3/4"M | 1 1/4“×1"M | |
| 3/4“×1/2"M | 1 1/4“×1 1/4"M | |
Adaptateur pivotant avec écrou en laiton, HS240-013
| TAILLE |
| 3/8“×3/8"F |
| 3/8“×1/2"F |
| 1/2“×1/2"F |
| 1/2“×3/4"F |
| 3/4“×3/4"F |
| 3/4“×1"F |
| 1“×1"F |
Adaptateur pivotant avec écrou en plastique, HS240-014
| TAILLE |
| 3/8“×3/8"F |
| 3/8“×1/2"F |
| 1/2“×1/2"F |
| 1/2“×3/4"F |
| 3/4“×3/4"F |
| 3/4“×1"F |
| 1“×1"F |
Connecteur en laiton, HS240-016
| TAILLE |
| 3/8“ |
| 1/2“ |
| 5/8“ |
| 3/4“ |
| 1“ |
| 1 1/4“ |
| 1 1/2“ |
| 2“ |
Adaptateur en polybutylène avec bague de sertissage PB, HS240-017
| TAILLE |
| 3/8“ |
| 1/2“ |
| 3/4“ |
Raccord coudé
Coude égal et Coude réducteur, HS240-006
| TAILLE | |
| 3/8“×3/8“ | 1/2“×3/8“ |
| 1/2“×1/2“ | 3/4“×1/2“ |
| 5/8“×5/8“ | 3/4“×5/8“ |
| 3/4“×3/4“ | 1“×3/4“ |
| 1“×1“ | |
| 1 1/4“×1 1/4“ | |
| 1 1/2“×1 1/2“ | |
| 2“×2“ | |
Coude femelle fileté, HS240-007
| TAILLE | ||
| 3/8“×1/2"F | 3/4“×3/4"F | 1 1/2“×1 1/2"F |
| 1/2“×1/2"F | 3/4“×1"F | 2“×2"F |
| 1/2“×3/4"F | 1“×3/4"F | |
| 5/8“×1/2"F | 1“×1"F | |
| 5/8“×3/4"F | 1 1/4“×1"F | |
| 3/4“×1/2"F | 1 1/4“×1 1/4"F | |
Coude mâle fileté, HS240-008
| TAILLE | ||
| 3/8“×1/2"M | 3/4“×3/4"M | 1 1/2“×1 1/2"M |
| 1/2“×1/2"M | 3/4“×1"M | 2“×2"M |
| 1/2“×3/4"M | 1“×3/4"M | |
| 5/8“×1/2"M | 1“×1"M | |
| 5/8“×3/4"M | 1 1/4“×1"M | |
| 3/4“×1/2"M | 1 1/4“×1 1/4"M | |
Coude femelle de sueur, HS240-009
| TAILLE |
| 3/8“×1/2"F |
| 1/2“×1/2"F |
| 1/2“×3/4"F |
| 5/8“×3/4"F |
| 3/4“×1/2"F |
| 3/4“×3/4"F |
| 1“×1"F |
Coude mâle de sueur, HS240-010
| TAILLE |
| 1/2“×1/2"M |
| 1/2“×3/4"M |
| 5/8“×3/4"M |
| 3/4“×3/4"M |
| 1“×1"M |
Coude pour plaque murale, HS240-011
| TAILLE |
| 3/8“×1/2"F |
| 1/2“×3/8"F |
| 1/2“×1/2"F |
| 3/4“×1/2"F |
| 3/4“×3/4"F |
Coude orientable avec écrou en plastique, HS240-015
| TAILLE |
| 3/8“×3/8"F |
| 3/8“×1/2"F |
| 1/2“×1/2"F |
| 1/2“×3/4"F |
| 3/4“×3/4"F |
Raccord en T
Té égal et Té de réduction, HS240-012
| TAILLE | ||||
| 3/8“×3/8“×3/8“ | 1/2“×1/2“×3/8“ | 1“×3/4“×1/2“ | 1 1/2“×1 1/4“×3/4“ | 2“×1 1/2“×1 1/2“ |
| 1/2“×1/2“×1/2“ | 1/2“×1/2“×3/4“ | 1“×1/2“×3/4“ | 1 1/2“×1 1/4“×1“ | 2“×2“×1/2“ |
| 5/8“×5/8“×5/8“ | 3/4“×3/4“×3/8“ | 1“×1/2“×1“ | 1 1/2“×1 1/4“×1 1/4“ | 2“×2“×3/4“ |
| 3/4“×3/4“×3/4“ | 3/4“×1/2“×1/2“ | 1 1/4“×1“×3/4“ | 1 1/2“×1 1/2“×1/2“ | 2“×2“×1“ |
| 1“×1“×1“ | 3/4“×1/2“×3/4“ | 1 1/4“×1“×1“ | 1 1/2“×1 1/2“×3/4“ | 2“×2“×1 1/4“ |
| 1 1/4“×1 1/4“×1 1/4“ | 3/4“×3/4“×1/2“ | 1 1/4“×1 1/4“×1/2“ | 1 1/2“×1 1/2“×1“ | 2“×2“×1 1/2“ |
| 1 1/2“×1 1/2“×1 1/2“ | 3/4“×3/4“×1“ | 1 1/4“×1 1/4“×3/4“ | 1 1/2“×1 1/2“×1 1/4“ | |
| 2“×2“×2“ | 1“×3/4“×1“ | 1 1/4“×1 1/4“×1“ | 2“×1 1/4“×1 1/4“ | |
| 3/8“×3/8“×1/2“ | 1“×1“×1/2“ | 1 1/2“×3/4“×3/4“ | 2“×1 1/2“×3/4“ | |
| 1/2“×3/8“×3/8“ | 1“×1“×3/4“ | 1 1/2“×1“×3/4“ | 2“×1 1/2“×1“ | |
| 1/2“×3/8“×1/2“ | 1“×3/4“×3/4“ | 1 1/2“×1“×1“ | 2“×1 1/2“×1 1/4“ | |
